SONOTEC presents New Broadband Parabolic Sensors for the SONAPHONE Digital Ultrasonic Testing Device

Detecting errors before they occur - that’s the objective of preventive maintenance. The HANNOVER MESSE will be addressing the topic of “Predictive Maintenance” with a dedicated exhibition area, where SONOTEC will be demonstrating how companies can save energy and improve the efficiency of the entire production cycle using SONAPHONE technology.



Sonaphone-Animation

From April 23 to 27, 2018, the ultrasound specialist will be presenting the new broadband parabolic sensor BS30 for the SONAPHONE digital ultrasonic testing device for the very first time, as part of the special exhibition in Hall 22.

The parabolic sensor BS30 for the SONAPHONE ultrasonic testing device can be used to detect leaks in compressed air, gas and vacuum systems as well as partial discharges over distances of up to 25 meters. The airborne sound sensor has been specially developed for the digital testing device. In addition to its range, the broadband sensor is also characterized by its directionality and its immunity to interference noise in the audible range. This allows for easy leak detection even in loud and challenging industrial environments.

 - Whereas comparable testing technology only allows for processing over a narrow frequency range, our sensors make it possible to carry out a completely new analysis of the ultrasound signal in the frequency range from 20 to 100 kHz, explains Hans-Joachim Münch, Managing Director of SONOTEC Ultraschallsensorik Halle GmbH, talking about the special features of the SONAPHONE sensors.

Sonaphone_sonotec

The multi-function ultrasonic testing device is used in preventive maintenance for, among other things: leak detection and evaluation, tightness testing of unpressurized systems, condition monitoring of machinery, checking valves and steam traps and detection of partial discharges.

In addition to the BS30, the ultrasound specialist also offers an airborne sound sensor and a structure-borne sound and temperature sensor for the SONAPHONE. Depending on the sensor, the multi-functional ultrasonic testing device can be used to detect and evaluate leaks and therefore reduce energy costs, to detect partial discharges and increase operational reliability, to detect potential weak points on bearings in good time in order to prevent any unplanned downtimes, and to assess the functioning of steam traps.

- The key benefit of our SONAPHONE can be summed up in one key word: efficiency. Often, preventing just a single downtime is enough to make up for the investment costs for the device, says Hans-Joachim Münch.

Thanks to its sturdy housing, the mobile ultrasonic testing device is suitable for use in industrial applications, and the SONAPHONE can be operated intuitively like a tablet via the 5-inch display with multi-touchscreen. A user-friendly design is also paramount when it comes to the software: The different apps help the service engineer throughout the entire testing process and contain all necessary information. Test reports can be created in just a few clicks, making time-consuming and error-prone paper hardcopy recordings a thing of the past.

Visit SONOTEC from April 23 to 27 at the “Predictive Maintenance” exhibition area at the HANNOVER MESSE in Hall 22, Stand A39.

www.sonotec.eu



SEE VIDEO: SONAPHONE - Innovative Ultrasonic Testing Device for Maintenance 4.0
